Part Number: THN08273 / Vendor ID Number: 10831 / Custom:
KYOCERA Precision Tools THN08273

KYOCERA Precision Tools THN08273
by KYOCERA Precision Tools

Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Qty
Product Overview
Kyocera MFAH 080RS6TMSF Metric Bore Diameter, 90 Degree Face Mill
Kyocera MFAH 080RS6TMSF Metric Bore Diameter, Standard Pitch, 6 Flute, 90 Degree Face Mill with a 80.00mm Cutting Diameter for Aluminum Facing, Finishing Applications
Product Availability
    Item is usually in stock, but we'll be in touch if there's a problem
Number of Flutes:
Chipbreaker:
Material:
Additional options that would change other selections
Insert Holding Method:
Additional options that would change other selections
Info & Guides
PDF
Technical Details
Details
Category:
Milling
Subcategory:
Indexable
Subtype:
Indexable Face Mills
Insert Holding Method:
Screw or Clamp
Material:
Steel
Number of Flutes:
6
Additional Manufacturer Part Number:
8858631
ANSI Part Number:
MFAH080RS6TMSF
Application:
Facing|Finish Milling
Bore Diameter (Inch/Metric):
Metric
California Prop 65 Item:
View
Coolant Through (Yes/No):
No
Country of Origin:
US, JAPAN, CHINA, SOUTH KOREA, OTHER
Cutter Pitch:
Standard Pitch
Discount Category Description:
Steel / Hardware
ECCN:
EAR99
Feature 1:
90 Degree Lead Angle Face Mill
Feature 2:
Application: Aluminum Facing, Finishing
Feature 3:
Low cutting forces minimize burrs and chipping for high quality machining
Feature 4:
Easily adjustable blade runout for efficient machining
Feature 5:
3 different cutting edge designs
Hand:
Right-Hand
Harmonized Code:
8466.10.0130
ISO Part Number:
MFAH080RS-6T-M-SF
Material Group / Grade:
GR99
Min Order Qty:
1
Number of Inserts:
6
Origin:
KOR
Pack Height:
4.488
Pack Length:
7.323
Pack Width:
4.646
Product URL:
https://app.catsy.com/app/share/739/o/collections/4004662142/digitalcatalog/item?sku=8858631
Series Description:
MFAH Milling
Series.1:
MFAH
Shipping Weight:
3.1636
Tool Style:
MFAH
Unit (inch/mm):
mm
UNSPSC:
23242106
UNSPSC Title:
Indexable Tool Bodies or Holders
Video 1:
https://www.youtube.com/watch?v=A-85rVJNNMk
[APMX] Maximum Depth of Cut (Decimal Inch):
0.1811
[APMX] Maximum Depth of Cut (mm):
4.60
[DCB] Connection Bore Diameter (Decimal Inch):
1.0630
[DCB] Connection Bore Diameter (mm):
27.00
[DCN] Cutting Diameter Minimum (Decimal Inch):
3.1496
[DCN] Cutting Diameter Minimum (mm):
80.00
[DCSFMS] Contact Surface Diameter Machine Side (De:
2.3622
[DCSFMS] Contact Surface Diameter Machine Side (mm:
60.00
[DCX] Cutting Diameter Maximum (Decimal Inch):
3.1496
[DCX] Cutting Diameter Maximum (mm):
80.00
[DC] Cutting Diameter (Decimal Inch):
3.1496
[DC] Cutting Diameter (mm):
80.00
[KAPR] Tool Entering Angle (Degree):
90
Manufactured By:
KYOCERA Precision Tools
