Item Sales Info
Part Number: 05176 / Vendor ID Number: 11735 / Custom:
Techniks 05176

Techniks 05176
by Techniks

Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Qty
Product Overview
DE23 x ER11M - 60
Double Ended Collet Chuck 23mm x ER11 - 16.6mm projection
Product Availability
    Item is usually in stock, but we'll be in touch if there's a problem
Shank Size:
Collet Series:
Additional options that would change other selections
Specific Products:
Info & Guides
2D Drawing
3D File
Technical Details
Details
Category:
Tooling Systems
Subcategory:
Tool Holders
Subtype:
Collet Chucks
Body Diameter:
23mm
Capacity Range (in):
0.019" - 0.281"
Capacity Range - Metric:
0.5 - 7.1mm
Collet Series:
ER11
Country of Origin:
Taiwan
Family:
Collet Chucks
Nose Diameter:
16mm
Overall Length:
93.2mm
Projection Length:
16.6mm
Shank Size:
23mm
Taper:
DE23
Taper Length:
60mm
Unit of Tool:
Metric
UNSPSC Code:
27112807
Weight:
0.4
Manufactured By:
Techniks
