Part Number: 7010292856 / Vendor ID Number: 10834 / Custom:
3M™ Venture Tape™ Double Sided Polyethylene Foam Glazing Tape VG716, White, 1/4 in x 150 ft, 62 mil,

3M™ Venture Tape™ Double Sided Polyethylene Foam Glazing Tape VG716, White, 1/4 in x 150 ft, 62 mil,
by 3M

Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Qty
Product Overview
VG716 DC 1/16 PE WT 1/4INX150FT 78/CV
3M™ Venture Tape™ Double Coated PE Foam Glazing Tape VG716 is 1/16" thick closed cell, crosslinked polyethylene foam tape coated with rubber based adhesive on one side and acrylic based adhesive on the other (liner side) with a 4 mil blue poly easy release liner.
Product Availability
    Item is usually in stock, but we'll be in touch if there's a problem
Info & Guides
Document
Data Sheet
Brochure
Technical Details
Details
Adhesive Type:
Rubber/Acrylic
Application:
Window and Door Glazing
Backing (Carrier) Material:
Polyethylene Foam
Base - Billing Unit:
ROL
Base - Item Quantity:
1
Base - Metric Gross Weight:
113.398 G
Base - Metric Height Dimension:
33.655 CM
Base - Metric Length Dimension:
0.635 CM
Base - Metric Width Dimension:
33.66 CM
Base - Unit:
ROL
Brand:
Venture Tape™
Catalog Number:
VG716
Consumer - Item Unit:
RLS
Consumer - Previous Packaging Level Quantity:
1
Consumer - Total Unit Quantity:
1
Country of Origin:
United States
Density (Imperial):
3
Density (Metric):
48.0 kg/m³
ECCN:
EAR99
Global Product Hierarchy:
Tapes > Foam Tapes > General Purpose Foam Tapes
Harmonized Tariff Schedule Nbr:
3919102055
Indoor/Outdoor:
Indoor/Outdoor
Legacy SKU:
70008930441
Maximum Operating Temperature (Celsius):
68.0 Degree Celsius
Maximum Operating Temperature (Fahrenheit):
155.0 Degree Fahrenheit
Minimum Operating Temperature (Celsius):
-10.0 Degree Celsius
Minimum Operating Temperature (Fahrenheit):
50.0 Degree Fahrenheit
Number of Adhesive Sides:
Double-sided
Overall Length (Imperial):
50.0 yd
Overall Length (Metric):
45.7 m
Overall Width (Imperial):
0.25 in
Overall Width (Metric):
6.35 mm
Pallet - Billing Unit:
ROL
Pallet - Customary Cubic Dimension:
128744.00197619293 ci
Pallet - Customary Gross Weight:
589.9989014365475 lbs
Pallet - Customary Height Dimension:
66.5 in
Pallet - Customary Length Dimension:
44.0 in
Pallet - Customary Net Weight:
515.9610599270001 lbs
Pallet - Customary Width Dimension:
44.0 in
Pallet - Item Quantity:
2106
Pallet - Item Unit:
RLS
Pallet - Metric Cubic Dimension:
2109736.2 CCM
Pallet - Metric Height Dimension:
168.91 CM
Pallet - Metric Length Dimension:
111.76 CM
Pallet - Metric Net Weight:
234.036 KG
Pallet - Metric Width Dimension:
111.76 CM
Pallet - Pallet Layer Quantity:
3
Pallet - Previous Packaging Level Quantity:
27
Pallet - Previous Packaging Level Unit:
BOX
Pallet - Shipping Container Per Layer Quantity:
9
Pallet - Total Unit Quantity:
2106
Pallet - Unit:
PAL
Part number:
VG716
Primary Liner:
Polyethylene Film
Primary Liner Thickness (Imperial):
4.0 mil
Primary Liner Thickness (Metric):
0.1 mm
Product Color:
White
Product Type.1:
Tape
Return Policy Description:
No Return
SAP ID:
7010292856
SAP Shelf Life In Days:
0
Shipper - Billing Unit:
ROL
Shipper - Customary Cubic Dimension:
4089.9562606211825 ci
Shipper - Customary Gross Weight:
19.998131802790244 lbs
Shipper - Customary Height Dimension:
20.5 in
Shipper - Customary Length Dimension:
14.124803149606299 in
Shipper - Customary Net Weight:
19.10966888618519 lbs
Shipper - Customary Width Dimension:
14.124803149606299 in
Shipper - Item Quantity:
78
Shipper - Item Unit:
RLS
Shipper - Metric Cubic Dimension:
67022.375 CCM
Shipper - Metric Height Dimension:
52.07 CM
Shipper - Metric Length Dimension:
35.877 CM
Shipper - Metric Net Weight:
8.668 KG
Shipper - Metric Weight:
9.071 KG
Shipper - Metric Width Dimension:
35.877 CM
Shipper - Previous Packaging Level Quantity:
78
Shipper - Previous Packaging Level Unit:
RLS
Shipper - Total Unit Quantity:
78
Shipper - Unit:
CS
Total Tape Thickness without Liner (Imperial):
66.5 mil
Total Tape Thickness without Liner (Metric):
1.7 mm
Unit of Use - Billing Unit:
ROL
Unit of Use - Customary Cubic Dimension:
43.8971251958252 ci
Unit of Use - Customary Gross Weight:
0.24999979607240747 lbs
Unit of Use - Customary Height Dimension:
13.25 in
Unit of Use - Customary Length Dimension:
0.25 in
Unit of Use - Customary Net Weight:
0.24499530272081077 lbs
Unit of Use - Customary Width Dimension:
13.251968503937007 in
Unit of Use - Item Quantity:
1
Unit of Use - Item Unit:
RLS
Unit of Use - Metric Cubic Dimension:
719.345 CCM
Unit of Use - Metric Height Dimension:
33.655 CM
Unit of Use - Metric Length Dimension:
0.635 CM
Unit of Use - Metric Net Weight:
111.128 G
Unit of Use - Metric Width Dimension:
33.66 CM
Unit of Use - Previous Packaging Level Quantity:
1
Unit of Use - Total Unit Quantity:
1
Unit of Use - Unit:
ROL
Unnamed: 108:
Easily die cut. Low application temperature Great chemical resistance. Low compression set. Better conformability, cushioning and vibration damping.
UNSPSC Tax Code:
31201500
Manufactured By:
3M
