Item Sales Info
Part Number: 7010375421 / Vendor ID Number: 10834 / Custom:
3M™ High Performance Double Coated Tape 9086, White, 1/2 in x 60 yd, 7.5 mil, 72 Roll/Case

3M™ High Performance Double Coated Tape 9086, White, 1/2 in x 60 yd, 7.5 mil, 72 Roll/Case
by 3M

Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Qty
Product Overview
9086 DC HI PRFM TP WT 1/2INX60YD 72/CV
3M™ High Performance Double Coated Tape 9086 features a specially-formulated acrylic adhesive that delivers very high initial tack and excellent peel and shear performance on a wide range of surfaces and materials. At 3.5 mils per side, the adhesive bonds to smooth, rough or textured surfaces. A 0.5 mil tissue carrier is conformable and hand-tearable for efficient processing and use.
Product Availability
    Item is usually in stock, but we'll be in touch if there's a problem
Info & Guides
Document
Document
Data Sheet
Brochure
Brochure
Technical Details
Details
Adhesive Type:
Modified Acrylic
Application:
Zero-Speed and General Splicing
Backing (Carrier) Material:
Tissue
Backing (Carrier) Thickness (Imperial):
0.5 mil
Backing (Carrier) Thickness (Metric):
0.013 mm
Base - Billing Unit:
ROL
Base - Item Quantity:
1
Base - Metric Gross Weight:
245.583 G
Base - Metric Length Dimension:
54.864 M
Base - Metric Width Dimension:
0.012 M
Base - Unit:
ROL
Brand:
3M™
Carrier Material:
Tissue
Catalog Number:
9086
Country of Origin:
Germany
ECCN:
EAR99
Global Product Hierarchy:
Tapes > Splicing & Tabbing Tapes
Harmonized Tariff Schedule Nbr:
4811412100
Indoor/Outdoor:
Both
Keywords:
3M, 3M High Performance Double Coated Tape 9086, high-performance tape, double coated tape, acrylic adhesive, high initial tack tape, excellent peel and shear performance, textured surfaces tape, hand-tearable tape, conformable tape, adhesive tape for vari
Legacy SKU:
70006701190
Maximum Operating Temperature (Celsius):
121.0 Degree Celsius
Maximum Operating Temperature (Fahrenheit):
250.0 Degree Fahrenheit
Minimum Operating Temperature (Fahrenheit):
-40.0 Degree Fahrenheit
Overall Length (Imperial):
60.0 yd
Overall Length (Metric):
54.86 m
Overall Width (Imperial):
0.5 in
Overall Width (Metric):
12.7 mm
Pallet - Billing Unit:
ROL
Pallet - Customary Cubic Dimension:
101168.70233740467 ci
Pallet - Customary Gross Weight:
1439.6185720672506 lbs
Pallet - Customary Height Dimension:
50.0 in
Pallet - Customary Length Dimension:
48.031496062992126 in
Pallet - Customary Net Weight:
1332.2446318927277 lbs
Pallet - Customary Width Dimension:
42.125984251968504 in
Pallet - Item Quantity:
2592
Pallet - Item Unit:
RLS
Pallet - Metric Cubic Dimension:
1657858.0 CCM
Pallet - Metric Height Dimension:
127.0 CM
Pallet - Metric Length Dimension:
122.0 CM
Pallet - Metric Net Weight:
604.296 KG
Pallet - Metric Width Dimension:
107.0 CM
Pallet - Pallet Layer Quantity:
4
Pallet - Previous Packaging Level Quantity:
36
Pallet - Previous Packaging Level Unit:
BOX
Pallet - Shipping Container Per Layer Quantity:
9
Pallet - Total Unit Quantity:
2592
Pallet - Unit:
PAL
Part number:
9086
Primary Liner:
Glassine Paper
Primary Liner Color:
White
Primary Liner Thickness (Imperial):
3.0 mil
Primary Liner Thickness (Metric):
0.08 mm
Product Color:
White
Product Form:
Roll
Return Policy Description:
0-30d:0%;31-180:15%;>180:no return
SAP ID:
7010375421
SAP Shelf Life In Days:
730
Shipper - Billing Unit:
ROL
Shipper - Customary Cubic Dimension:
2182.37873483621 ci
Shipper - Customary Gross Weight:
38.98213719953005 lbs
Shipper - Customary Height Dimension:
11.299212598425196 in
Shipper - Customary Length Dimension:
13.89763779527559 in
Shipper - Customary Net Weight:
37.00679533035355 lbs
Shipper - Customary Width Dimension:
13.89763779527559 in
Shipper - Item Quantity:
72
Shipper - Item Unit:
RLS
Shipper - Metric Cubic Dimension:
35762.78 CCM
Shipper - Metric Height Dimension:
28.7 CM
Shipper - Metric Length Dimension:
35.3 CM
Shipper - Metric Net Weight:
16.786 KG
Shipper - Metric Weight:
17.682 KG
Shipper - Metric Width Dimension:
35.3 CM
Shipper - Previous Packaging Level Quantity:
72
Shipper - Previous Packaging Level Unit:
RLS
Shipper - Total Unit Quantity:
72
Shipper - Unit:
CS
Substrate:
Cardboard
Total Tape Thickness without Liner (Imperial):
7.5 mil
Total Tape Thickness without Liner (Metric):
0.19 mm
Unit of Use - Billing Unit:
ROL
Unit of Use - Customary Cubic Dimension:
30.310798810574 ci
Unit of Use - Customary Gross Weight:
0.541417837341488 lbs
Unit of Use - Customary Net Weight:
0.5139835134352018 lbs
Unit of Use - Item Quantity:
1
Unit of Use - Item Unit:
RLS
Unit of Use - Metric Cubic Dimension:
496.705 CCM
Unit of Use - Metric Net Weight:
233.139 G
Unit of Use - Previous Packaging Level Quantity:
1
Unit of Use - Total Unit Quantity:
1
Unit of Use - Unit:
ROL
Unnamed: 108:
Bonds to a wide variety of substrates including textured surfaces and difficult-to-stick-to plastics Double coated tissue carrier with 3.5 mil adhesive on each side 375 adhesive family provides high initial tack, excellent peel and shear performance 0.5 mi
UNSPSC Tax Code:
31201500
Manufactured By:
3M
