Item Sales Info
Part Number: 7100190333 / Vendor ID Number: 10834 / Custom:
3M™ Glass Cloth Electrical Tape 79, .75" X 72 YDS, 3" PAPER CORE

3M™ Glass Cloth Electrical Tape 79, .75" X 72 YDS, 3" PAPER CORE
by 3M

Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Qty
Product Overview
79 TAPE .75IN X 72 YDS, 3IN PAPER CORE
3M™ Glass Cloth Electrical Tape 79 is a printable tape used in coils/transformers and motor applications. It includes an outer wrap for bobbin wound coils, banding arbor wound coils, lead pad hold downs, end turns and lead anchors, as well as connections. This tape is 600V rated and withstands a temperature range of 32 to 302 °F (0 to 150 °C).
Product Availability
    Item is usually in stock, but we'll be in touch if there's a problem
Info & Guides
Brochure
Brochure
RDS (Regulatory Data Sheet)
AIS (Article Information Sheet)
Technical Details
Details
Adhesive Type:
Acrylic
Base - Billing Unit:
ROL
Base - Item Quantity:
1
Base - Metric Gross Weight:
281.227 G
Base - Metric Height Dimension:
19.05 MM
Base - Metric Length Dimension:
139.7 MM
Base - Metric Width Dimension:
139.7 MM
Base - Unit:
ROL
Brand:
3M™
Catalog Number:
79- 0.75"X72YD
Consumer - Billing Unit:
ROL
Consumer - Customary Cubic Dimension:
22.70083280324041 ci
Consumer - Customary Gross Weight:
0.6199994060746656 lbs
Consumer - Customary Height Dimension:
0.75 in
Consumer - Customary Length Dimension:
5.5 in
Consumer - Customary Net Weight:
0.6199994060746656 lbs
Consumer - Customary Width Dimension:
5.5 in
Consumer - Item Quantity:
1
Consumer - Item Unit:
RLS
Consumer - Metric Cubic Dimension:
0.372 CDM
Consumer - Metric Height Dimension:
19.05 MM
Consumer - Metric Length Dimension:
139.7 MM
Consumer - Metric Net Weight:
281.227 G
Consumer - Metric Width Dimension:
139.7 MM
Consumer - Previous Packaging Level Quantity:
1
Consumer - Total Unit Quantity:
1
Consumer - Unit:
ROL
Country of Origin:
United States
Global Product Hierarchy:
Tapes > Electrical Tapes > Glass Cloth Electrical Tapes
Keywords:
3M, 3M Glass Cloth Electrical Tape, electrical tape, glass cloth tape, acrylic adhesive, pressure-sensitive tape, motor applications, transformer applications, coil insulation, 600V rated tape, high-temperature tape, resin absorption tape, varnish absorpti
Legacy SKU:
80000216236
Overall Width (Imperial):
0.75 in
Overall Width (Metric):
19.05 mm
Pallet - Billing Unit:
ROL
Pallet - Customary Cubic Dimension:
93122.23348856147 ci
Pallet - Customary Gross Weight:
1233.997829372659 lbs
Pallet - Customary Height Dimension:
46.2 in
Pallet - Customary Length Dimension:
48.0 in
Pallet - Customary Net Weight:
1071.358409313631 lbs
Pallet - Customary Width Dimension:
42.0 in
Pallet - Item Quantity:
1728
Pallet - Item Unit:
RLS
Pallet - Metric Cubic Dimension:
1.526 M3
Pallet - Metric Height Dimension:
117.348 CM
Pallet - Metric Length Dimension:
121.92 CM
Pallet - Metric Net Weight:
485.96 KG
Pallet - Metric Width Dimension:
106.68 CM
Pallet - Pallet Layer Quantity:
4
Pallet - Previous Packaging Level Quantity:
36
Pallet - Previous Packaging Level Unit:
BOX
Pallet - Shipping Container Per Layer Quantity:
9
Pallet - Total Unit Quantity:
1728
Pallet - Unit:
PAL
Part number:
79- 0.75"X72YD
Product Color:
White
SAP ID:
7100190333
SAP Shelf Life In Days:
0
Shipper - Billing Unit:
ROL
Shipper - Customary Cubic Dimension:
1558.28707326706 ci
Shipper - Customary Gross Weight:
33.29099208613231 lbs
Shipper - Customary Height Dimension:
10.3 in
Shipper - Customary Length Dimension:
12.3 in
Shipper - Customary Net Weight:
29.75997149158395 lbs
Shipper - Customary Width Dimension:
12.3 in
Shipper - Item Quantity:
48
Shipper - Item Unit:
RLS
Shipper - Metric Cubic Dimension:
25535.75 CCM
Shipper - Metric Height Dimension:
26.162 CM
Shipper - Metric Length Dimension:
31.242 CM
Shipper - Metric Net Weight:
13498.896 G
Shipper - Metric Weight:
15100.54 G
Shipper - Metric Width Dimension:
31.242 CM
Shipper - Previous Packaging Level Quantity:
48
Shipper - Previous Packaging Level Unit:
RLS
Shipper - Total Unit Quantity:
48
Shipper - Unit:
CS
Total Tape Thickness without Liner (Imperial):
7.0 mil
Total Tape Thickness without Liner (Metric):
0.178 mm
Unnamed: 108:
Pressure-sensitive, acrylic adhesive offers optimized adherence Glass cloth backing ensures maximum stability Designed for coils/transformers and motor applications Printable and has the ability to absorb resin and varnishes Withstands a temperature range
UNSPSC Tax Code:
31200000
Manufactured By:
3M
