Item Sales Info
Part Number: 7000132172 / Vendor ID Number: 10834 / Custom:
3M™ Glass Cloth Electrical Tape 27, White, Rubber Thermosetting Adhesive, 2 in x 60 yd (48,8 mm x 55

3M™ Glass Cloth Electrical Tape 27, White, Rubber Thermosetting Adhesive, 2 in x 60 yd (48,8 mm x 55
by 3M

Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Qty
Product Overview
27 TAPE 2 X 60 YD BULK
3M™ Glass Cloth Electrical Tape 27 is a 0.18 mm (7 mil) woven insulating tape with pressure sensitive rubber thermosetting adhesive. This tape is designed to operate in 600 volt dry applications requiring high mechanical strength and resistance to high temperatures. The adhesive is specially designed and prepared to provide corrosion protection.
Product Availability
    Item is usually in stock, but we'll be in touch if there's a problem
Info & Guides
Document
Document
Data Sheet
Brochure
Brochure
Technical Details
Details
Adhesive Type:
Rubber
Application:
Insulation
Backing (Carrier) Material:
Glass Cloth
Base - Billing Unit:
ROL
Base - Customary Height Dimension:
5.625
Base - Customary Length Dimension:
2
Base - Customary Width Dimension:
5.625196850393701
Base - Item Quantity:
1
Base - Metric Gross Weight:
615.1 G
Base - Metric Height Dimension:
142.875 MM
Base - Metric Length Dimension:
50.8 MM
Base - Metric Width Dimension:
142.88 MM
Base - Unit:
ROL
Brand:
3M™
Catalog Number:
27 2"X60YD
Country of Origin:
United States
Dielectric Strength:
2725.0 V
ECCN:
EAR99
Global Product Hierarchy:
Tapes > Electrical Tapes > Glass Cloth Electrical Tapes
Harmonized Tariff Schedule Nbr:
7019659090
Keywords:
Electrical tape, 3M glass cloth tape, glass cloth tape, glass cloth tape 27, 3m tape 27, glass cloth electrical tape
Legacy SKU:
80012020162
Maximum Operating Temperature (Celsius):
150.0 Degree Celsius
Maximum Operating Temperature (Fahrenheit):
302.0 Degree Fahrenheit
Minimum Operating Temperature (Celsius):
0.0 Degree Celsius
Overall Length (Imperial):
60.0 yd
Overall Length (Metric):
55.0 m
Overall Width (Imperial):
2.0 in
Overall Width (Metric):
50.8 mm
Pallet - Billing Unit:
ROL
Pallet - Customary Cubic Dimension:
101726.58140591871 ci
Pallet - Customary Gross Weight:
1044.9911227563198 lbs
Pallet - Customary Height Dimension:
51.181102362204726 in
Pallet - Customary Length Dimension:
47.63779527559055 in
Pallet - Customary Net Weight:
976.365629783411 lbs
Pallet - Customary Width Dimension:
41.732283464566926 in
Pallet - Item Quantity:
720
Pallet - Item Unit:
RLS
Pallet - Metric Cubic Dimension:
1.667 M3
Pallet - Metric Height Dimension:
1.3 M
Pallet - Metric Length Dimension:
1.21 M
Pallet - Metric Net Weight:
442.872 KG
Pallet - Metric Width Dimension:
1.06 M
Pallet - Pallet Layer Quantity:
4
Pallet - Previous Packaging Level Quantity:
36
Pallet - Previous Packaging Level Unit:
BOX
Pallet - Shipping Container Per Layer Quantity:
9
Pallet - Total Unit Quantity:
720
Pallet - Unit:
PAL
Part number:
27 2"X60YD
Product Color:
White
Sales Unit:
RO
SAP ID:
7000132172
SAP Shelf Life In Days:
1825
Shipper - Billing Unit:
ROL
Shipper - Customary Cubic Dimension:
2073.9773763012095 ci
Shipper - Customary Gross Weight:
28.19932795606769 lbs
Shipper - Customary Height Dimension:
11.5748031496063 in
Shipper - Customary Length Dimension:
13.385826771653543 in
Shipper - Customary Net Weight:
27.12126749398364 lbs
Shipper - Customary Width Dimension:
13.385826771653543 in
Shipper - Item Quantity:
20
Shipper - Item Unit:
RLS
Shipper - Metric Cubic Dimension:
33986.4 CCM
Shipper - Metric Height Dimension:
0.294 M
Shipper - Metric Length Dimension:
0.34 M
Shipper - Metric Net Weight:
12.302 KG
Shipper - Metric Weight:
12.791 KG
Shipper - Metric Width Dimension:
0.34 M
Shipper - Previous Packaging Level Quantity:
20
Shipper - Previous Packaging Level Unit:
RLS
Shipper - Total Unit Quantity:
20
Shipper - Unit:
CS
Specifications Met:
CSA Certified
Tape Grade:
Professional
Target Warehouse Location Lead Time:
2 days
Total Tape Thickness without Liner (Imperial):
7.0 mil
Total Tape Thickness without Liner (Metric):
0.178 mm
Unit of Use - Billing Unit:
ROL
Unit of Use - Customary Cubic Dimension:
63.28345333856022 ci
Unit of Use - Customary Gross Weight:
1.356063374699182 lbs
Unit of Use - Customary Height Dimension:
5.625 in
Unit of Use - Customary Length Dimension:
2.0 in
Unit of Use - Customary Net Weight:
1.356063374699182 lbs
Unit of Use - Customary Width Dimension:
5.625196850393701 in
Unit of Use - Item Quantity:
1
Unit of Use - Item Unit:
RLS
Unit of Use - Metric Cubic Dimension:
1037.03 CCM
Unit of Use - Metric Height Dimension:
142.875 MM
Unit of Use - Metric Length Dimension:
50.8 MM
Unit of Use - Metric Net Weight:
615.1 G
Unit of Use - Metric Width Dimension:
142.88 MM
Unit of Use - Previous Packaging Level Quantity:
1
Unit of Use - Total Unit Quantity:
1
Unit of Use - Unit:
ROL
Unnamed: 108:
0.18 mm (7-mil) woven insulating glass cloth tape with pressure-sensitive rubber thermosetting adhesive Designed to operate in 600 volt dry applications requiring high mechanical strength and resistance to high temperatures Adhesive is specially designed a
UNSPSC Tax Code:
15121804
Manufactured By:
3M
