Part Number: 7000123420 / Vendor ID Number: 10834 / Custom:
3M™ Adhesive Transfer Tape 9502, Clear, 24 in x 180 yd, 2 mil, 1 Roll/Case

3M™ Adhesive Transfer Tape 9502, Clear, 24 in x 180 yd, 2 mil, 1 Roll/Case
by 3M

Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Qty
Product Overview
9502 24 IN X180 YD 1/CV
3M™ Adhesive Transfer Tape 9502 features 3M™ Industrial Acrylic Adhesive 220, which provides a good bond to HSE materials. This 2.3 mil adhesive is applied to a 4.2 mil polycoated kraft (PCK) paper liner, which protects it until it is ready to be bonded to the substrate.
Product Availability
    Item is usually in stock, but we'll be in touch if there's a problem
Info & Guides
Document
Document
Data Sheet
Brochure
Technical Details
Details
Adhesive Type:
Acrylic
Base - Billing Unit:
ROL
Base - Customary Length Dimension:
180.0 LNYD
Base - Customary Width Dimension:
24.0 INCH
Base - Item Quantity:
1
Base - Metric Gross Weight:
18.144 KG
Base - Metric Length Dimension:
164.592 M
Base - Metric Width Dimension:
0.609 M
Base - Unit:
ROL
Brand:
3M™
Catalog Number:
9502
Country of Origin:
United States
ECCN:
EAR99
Global Product Hierarchy:
Tapes > Bonding, Mounting & Transfer Tapes > Adhesive Transfer Tapes
Harmonized Tariff Schedule Nbr:
3506915000
Indoor/Outdoor:
Indoor/Outdoor
Keywords:
3M, 3M Adhesive Transfer Tape 9502, adhesive transfer tape, industrial acrylic adhesive, bonding solutions, high surface energy materials, metal bonding, painted metal bonding, nameplate attachment, graphic attachment, polycoated kraft paper liner, pressur
Legacy SKU:
70006103736
Maximum Operating Temperature (Celsius):
177.0 Degree Celsius
Maximum Operating Temperature (Fahrenheit):
350.0 Degree Fahrenheit
Minimum Operating Temperature (Celsius):
-40.0 Degree Celsius
Minimum Operating Temperature (Fahrenheit):
-40.0 Degree Fahrenheit
Overall Length (Imperial):
180.0 yd
Overall Length (Metric):
164.59 m
Overall Width (Imperial):
24.0 in
Overall Width (Metric):
609.6 mm
Pallet - Billing Unit:
ROL
Pallet - Customary Cubic Dimension:
65295.40618136354 ci
Pallet - Customary Gross Weight:
515.8816935126135 lbs
Pallet - Customary Height Dimension:
32.28346456692913 in
Pallet - Customary Length Dimension:
48.031496062992126 in
Pallet - Customary Net Weight:
425.5627139407129 lbs
Pallet - Customary Width Dimension:
42.125984251968504 in
Pallet - Item Quantity:
12
Pallet - Item Unit:
RLS
Pallet - Metric Cubic Dimension:
1.07 M3
Pallet - Metric Height Dimension:
82.0 CM
Pallet - Metric Length Dimension:
122.0 CM
Pallet - Metric Net Weight:
193.032 KG
Pallet - Metric Width Dimension:
107.0 CM
Pallet - Pallet Layer Quantity:
1
Pallet - Previous Packaging Level Quantity:
12
Pallet - Previous Packaging Level Unit:
BOX
Pallet - Shipping Container Per Layer Quantity:
12
Pallet - Total Unit Quantity:
12
Pallet - Unit:
PAL
Part number:
9502
Primary Liner:
58# Polycoated Kraft Paper
Primary Liner Color:
Tan
Primary Liner Thickness (Imperial):
4.2 mil
Primary Liner Thickness (Metric):
0.11 mm
Return Policy Description:
0-30d:0%;31-180:15%;>180:no return
Sales Unit:
RO
SAP ID:
7000123420
SAP Shelf Life In Days:
730
Shipper - Billing Unit:
ROL
Shipper - Customary Cubic Dimension:
3348.854620937588 ci
Shipper - Customary Gross Weight:
40.00067285082419 lbs
Shipper - Customary Height Dimension:
27.362204724409448 in
Shipper - Customary Length Dimension:
11.062992125984252 in
Shipper - Customary Net Weight:
35.46355949505941 lbs
Shipper - Customary Width Dimension:
11.062992125984252 in
Shipper - Item Quantity:
1
Shipper - Item Unit:
RLS
Shipper - Metric Cubic Dimension:
54877.895 CCM
Shipper - Metric Height Dimension:
69.5 CM
Shipper - Metric Length Dimension:
28.1 CM
Shipper - Metric Net Weight:
16.086 KG
Shipper - Metric Weight:
18.144 KG
Shipper - Metric Width Dimension:
28.1 CM
Shipper - Previous Packaging Level Quantity:
1
Shipper - Previous Packaging Level Unit:
RLS
Shipper - Total Unit Quantity:
1
Shipper - Unit:
CS
Target Warehouse Location Lead Time:
2 days
Total Tape Thickness without Liner (Imperial):
2.3 mil
Total Tape Thickness without Liner (Metric):
0.058 mm
Unit of Use - Billing Unit:
ROL
Unit of Use - Customary Cubic Dimension:
3348.854620937588 ci
Unit of Use - Customary Gross Weight:
40.00067285082419 lbs
Unit of Use - Customary Net Weight:
35.46355949505941 lbs
Unit of Use - Item Quantity:
1
Unit of Use - Item Unit:
RLS
Unit of Use - Metric Cubic Dimension:
54877.895 CCM
Unit of Use - Metric Net Weight:
16.086 KG
Unit of Use - Previous Packaging Level Quantity:
1
Unit of Use - Total Unit Quantity:
1
Unit of Use - Unit:
ROL
Unnamed: 108:
2 mil nominal 220 adhesive offers good sheer strength Good peel adhesion to HSE (high surface energy) materials PCK liner protects adhesive and peels away quickly for easy handling Economical solution for a variety of general bonding applications
UNSPSC Tax Code:
13111200
Manufactured By:
3M
